Shanghai W-Ibeda Automotive Test Tech. Co., Ltd.was established in December 2016, Shanghai W-Ibeda Automotive Hybrid Powertrain Technology Center Co., Ltd.was established in February 2018, and Shanghai W-Ibeda New Intelligent Technology Co.,Ltd was established in January 2022, all of which belong to Shanghai W-Ibeda High Tech. Group. Co., Ltd.In accordance with the third-party laboratory management requirements recognized by the national laboratory, we provide comprehensive technical services such as R&D testing, performance testing and quality evaluation for various types of automobile (new energy) and powertrain for domestic and foreign enterprises.
POWERTRAIN INNOVATION PROMOTES SOCIAL DEVELOPMENT
W-Ibeda test consists of three bases: Pudong electric test, Jiading hybrid test and Jiading new intelligent test.
With a scientific, rigorous, enterprising and innovative spirit, we provide customers with high-quality, standardized and efficient test technical services in the field of automotive (new energy) and power systems.
Provide testing services, engineering consulting (design, validation, benchmarking optimization) and technology development for automotive powertrains.
浦东、嘉定
浦东、嘉定
德国
Power: 180 kW Torque: 430 N·m Speed: 18000 r/min
Power: 250 kW Torque: 490 N·m Speed: 8000 r/min
25 kW, 50 kW, 200 kW, 400 kW
Power: 266 kW Torque: 3600 N·m Speed: 3300 r/min Temperature: -40 ~ 150 °C
25 kW, 50 kW, 200 kW, 400 kW
Yokogawa W5000, 7-channel and 4-channel models.
Power: 250 kW Torque: 500 N·m Speed: 8000 r/min Suitable for 48V Mild-Hybrid Testing
25 kW, 50 kW, 200 kW
Yokogawa W5000, 7-channel and 4-channel models.
Power: 200 kW Torque: 450 N·m Speed: 20000 r/min
Power: 250 kW Torque: 500 N·m Speed: 8000 r/min
25 kW, 50 kW, 200 kW, 400 kW
Power: 180 kW Torque: 430 N·m Speed: 18000 r/min
Power: 266 kW Torque: 3600 N·m Speed: 3300 r/min
Power: 380 kW Torque: 4000 N·m Speed: 4500 r/min
Power: 250 kW Torque: 500 N·m Speed: 8000 r/min
200 kW, 400 kW
Power: 20 kW Torque: 125 N·m Speed: 8000 r/min
25 °C ~ 120 °C
Power: 1.06 kW Torque: 1.68 N·m Speed: 8000 r/min
-40 °C ~ 150 °C
Wiper, seat, window motors, etc.
Compliant with IP6X
IPX7
Compliant with Neutral Salt-spray Test
Products comply with GB / JIS / JEC / JEM standards.
48-inch (1219 mm) chrome-plated rollers
150 kW / 220 kW TMEIC motors
Compact modular design ensures high flexibility and compatibility
Sun Simulation Intensity: 1000 W/m²
Accuracy exceeding EPA requirements
Maximum test speed: 210 km/h
Overload protection
High-low temperature environmental chamber (-40 ~ 60 °C)
Built-in DC fast-charging station inside test chamber
TMEIC 48-inch 4WD dual-motor chassis dynamometer
Suitable for testing 4-wheel-drive and 2-wheel-drive light-to-medium-duty vehicles (with high-low temperature environmental chamber)
GB/T 18488‑2024 Drive Motor System for Electric Vehicles, Test Methods
GB/T 29307‑2012, Reliability Test Methods of Drive Motor System for Electric Vehicles
GB/T 28046‑2011, Road vehicles — Environmental conditions and testing for electrical and electronic equipment — Part 4: Climatic load
GB/T 2423.1‑2008, Environmental testing for electric and electronic products — Part 2: Test methods — Test A: Low‑temperature
GB/T 2423.2‑2008, Environmental testing for electric and electronic products — Part 2: Test methods — Test B: High‑temperature
GB/T 2423.17‑2008, Environmental testing for electric and electronic products — Part 2: Test methods — Test Ka: Salt mist
GB/T 2423.22‑2012, Environmental testing for electric and electronic products — Part 2: Test methods — Test N: Change of temperature
GB/T 2423.34‑2012, Environmental testing for electric and electronic products — Part 2: Test methods — Test Z/AD: Composite temperature‑humidity cyclic test
GB/T 28046‑3‑2011, Road vehicles — Environmental conditions and testing for electrical and electronic equipment — Part 3: Mechanical loads
GB/T 3859.1‑2013, Semiconductor convertors — General requirements and line‑commutated convertors — Part 1‑1: Specifications of basic requirements
GB/T 22719.1‑2008, Inter‑turn insulation of random wound windings for AC low‑voltage motors — Part 1: Test methods
QC/T 568‑2019, Specifications and bench test methods for automobile mechanical transmission assemblies
GB/T 4942.1‑2006, Rotating machines — Protection provided by integral design (IP code) — Classification
In the 5th Batch of Filing‑up Information for Inspection and Testing Institutions, the inspection item of Huayi Testing is “Drive motor and controller for electric vehicles”, the inspection basis is “GB/T 18488.1‑2015, GB/T 18488.2‑2015”, and the applied inspection scope covers “New‑energy vehicle components”.
IEC 62619:2017, Secondary cells and batteries containing alkaline or other non‑acid electrolytes — Safety requirements for secondary lithium cells and batteries for industrial applications
IEC 63056:2020, Secondary cells and batteries containing alkaline or other non‑acid electrolytes — Safety requirements for secondary lithium cells and batteries for use in electrical energy storage systems
GB/T 18297‑2024, Performance test code for road vehicle engines‑Clause 8.10: Blow‑by test
GB/T 19055‑2024, Automotive engine reliability test methods‑Clause 9.4: Rated‑power test
